DesignateIR-V™ Three Beam Laser ODG / Green Visible Laser / Infrared Laser / VCSEL IR Illuminator / Special Edition OD Green / All New ARISAKA Defense Ambidextrous Fire Button & Aluminum Mounting Plate / In Stock For Immediate Delivery
$879.00
- Extreme Power 130 mW Class 3R VCSEL IR Illuminator
Made in the USA, the Designate IR-V laser is the smallest and lightest, dual beam, tactical rifle laser available today. Built from synthetic nylon, this laser is designed to withstand recoil and will perform in all weather conditions. The Designate IR-V's set-it, forget-it zero allows the user to zero the visible laser once. Then, both laser sights are precisely co-witnessed for accuracy. The laser's small footprint lies below the weapons line of sight and allows the user to effortlessly switch to iron sights. The user controls have been carefully engineered for minimal drag, reliability, and ease of use.
a
| Specifications | |
|---|---|
| Green Visible Laser / Infrared Laser / VCSEL Illuminator | Yes |
| Fire Button Placement | Innovative |
| Laser / Illuminator Operation | Green / Infrared Laser / Infrared Illuminator |
| Remote Switch Connector | MIL-STD Crane |
| Remote Pressure Switch | Optional |
| Rail Mount | MIL-STD 1913 Picatinny |
| Fire Control Button | Momentary/Constant |
| Selector Switch | Vis/Off/IR/IR & Illuminator |
| Activation Light | Intuitive "User Only" |
| Windage / Elevation | Adjustable |
| Technical Specifications | |
| Size / Dimensions | (L) 3.8" x (W) 2.9" x (H) .5" |
| Weight (with Battery) | 6.3 oz |
| Battery | (1) CR123 + .56 oz |
| Battery Life | > 5 hours |
| Environmental | IP68 |
| Warranty | 2 years |
| Visible Laser: Green | |
| Output Power | > 5.0 mW Class 3R |
| Beam Divergence | 0.5 mrad |
| Wavelength | 520 nm |
| Range | > 50 m Daylight |
| IR Laser: Infrared | |
| Output Power | > 2.5 mW Class 3R |
| Beam Divergence | 0.5 mrad |
| Wavelength | 830 nm |
| Range | > 1000 m |
| VCSEL Illuminator: Infrared | |
| Output Power | > 130 mW Class 3R |
| Beam Divergence | 3 Degree |
| Wavelength | 850 nm |
| Range | > 300 m |
- Availability: In Stock
- Model: DesignateIR-V
-
